Designed to accelerate your digital transformation (DX) journey, new Apeos 4570 series with its smart
and seamless integration features present itself as a trusted digital partner.
| SPECIFICATION | DETAILS |
|---|---|
| Model | Apeos 4570 |
| Warm-Up Time*2 |
[Embedded Plug-ins / Custom Services] *3 When enabled: 30 seconds or less (23 degrees Celsius room temperature) When disabled: 24 seconds or less (23 degrees Celsius room temperature) |
| First Output Speed | 3.6 sec. (A4 LEF) |
| Continuous Output Speed*5 | 45 ppm |
| Memory | HDD*1 | 4 GB (Max: 4 GB) | 128 GB |
| Dimensions*9 | W 620 x D 720 x H 1,119 mm |
| Weight*9 | 125 kg |
| Power Supply | AC220-240 V +/- 10 %, 10 A, 50/60 Hz common |
| Maximum Power Consumption |
2.2 kW (AC220 V +/- 10%), 2.4 kW (AC240 V +/- 10%) Sleep mode: 0.5 W (AC230 V), Ready mode: 82 W (AC230 V) |
| Multiple Copy | Up to 999 copies |
| Printing Resolution | 600 × 600 dpi (Text / Text-Photo / Photo / Map) |
| Continuous Print Speed*1 | Same as the Basic Specifications / Copy Function |
| Paper Sizes |
Max SRA3 (320 × 450 mm), 12 × 18″ (305 × 457 mm), A3 [12 × 19″ (305 × 483 mm), 320 × 483 mm when using Bypass Tray] Min Image loss width*4 |
| Paper Input Capacity*6 |
Standard : Tandem Tray Model: 520 sheets x 2-tray + 840 sheets + 1,230 sheets + Bypass Tray 90 sheets
Optional : Tandem Tray Module: 840 sheets + 1,230 sheets Max : Tandem Tray Model: 6,140 sheets (Standard + High Capacity Feeder B2) |
| Paper Output Capacity*8 |
Upper Center: 250 sheets (A4 LEF) Lower Center: 250 sheets (A4 LEF) |
| Paper Weight*5 |
Paper Tray : 52 to 300 gsm
Bypass Tray : 52 to 300 gsm |
